石 墨 簡 介
石墨是用焦碳粉和石墨粉或加碳黑做基料,用瀝青為粘結劑,經模壓成型在高溫下燒制而成的。一般將燒結石分為二種。一種為碳素石墨,以稱碳石墨,其特點是質硬、脆;另一種為石墨化石墨,以稱電化石墨,其特點是質軟、強度低,自潤滑性能好。

石墨具有優良的耐腐蝕性能。其化學穩定性能很高,在空氣中400℃以下穩定,除強氧化性介質如王水、鉻酸、濃硫酸及鹵素外,可耐其它酸、堿、鹽類及一切有機化合物的腐蝕。石墨的耐腐蝕程度一般隨基料的種類和浸漬劑的不同而異。

石墨是機械密封摩擦付材料中用量最大,使用范圍最廣的一種材料。它具有優良的耐腐蝕性能,除了強氧化性介質外,可以耐各種濃度的酸、堿、鹽類及一切有機化合物的腐蝕。同特別好的自潤滑性和低的摩擦系數,與鋼對磨時,摩擦系數為0.04-0.05,經浸漬處理的碳石墨在流體動力潤滑條件下,其摩擦系數在0.08-0.1范圍內。石墨具有很高的導熱系數(100~110千卡/米·時·度),較低的線膨脹系數(2~3×10-6℃)以及良好的耐溫急變性能和加工性能,可以進行各種機械加工。
Graphite is the widest and most quantity materials used in the machine seal parts. It has a good erode-resistant ability. It can stand against cauterization from acid, alkali, salt and all organic compound except strong oxidation material.
Because of it's special ideal lubricative ability, the rub coefficient is between with 0.04 and 0.05 when it is rubbed with steel. With dipping treatment, under the situation of hydrokinetics, the rub coefficient is between with 0.08 and 0.10.
Graphite has a high heat-transmiting coeficient(100~110kilo-calorie/metre hour degree), and a lower line expanding coefficient(2~3×10-6℃), favorable anti-temperature deformationand machining ability. It can be processed by several kings of mechanical means.
型號 |
材料類型 |
抗折強度
公斤/厘米2 |
抗壓強度
公斤/厘米2
|
肖氏強度
HS |
假比重
克/厘米2 |
氣孔率
% |
熱膨脹系數
×10-6℃ |
使用溫度
℃
|
M121 |
碳石墨 |
260 |
750 |
65 |
1.56 |
17 |
4.0 |
350 |
M106H |
浸環氧
樹脂
|
300 |
1100 |
60 |
1.60 |
5 |
11.0 |
200 |
M120H |
420 |
900 |
60 |
1.68 |
5 |
11.0 |
200 |
M204H |
300 |
700 |
40 |
1.90 |
5 |
8.0 |
200 |
M650H |
600 |
980 |
55 |
2.2 |
3 |
7.0 |
300 |
M106K |
碳石墨
浸漬呋喃樹脂 |
570 |
1200 |
80 |
1.69 |
5 |
11.0 |
220 |
M205K |
浸呋喃樹脂 |
500 |
1800 |
75 |
2.15 |
5 |
10.0 |
200 |
M232L |
碳石墨浸鋁合金 |
1000 |
2000 |
40 |
2.15 |
4 |
6.0 |
400 |
M106Y |
碳石墨浸漬
巴氏合金 |
600 |
2000 |
60 |
2.36 |
5 |
6.0 |
180 |
M232Y |
400 |
1500 |
50 |
2.06 |
5 |
6.0 |
180 |

|
